外墻保溫板復合熱壓機組 鋁蜂窩填充復合、巖棉填充復合熱壓機 BY625 x 43/40
首頁 >產品中心>復合材料壓機(蜂窩復合等)
外墻保溫板復合熱壓機組 鋁蜂窩填充復合、巖棉填充復合熱壓機 BY625 x 43/40
  • 產品詳細


1、皮帶運輸機 BZY1113.5/64/850

名稱Name:皮帶運輸機

型號Model:BZY1113.5/64/850

(1)皮帶運輸長度 Belt conveying length:6400mm

(2)皮帶運輸寬度 Belt conveying breadth:1350mm

(3)工作高度 Working height:850mm

(4)裝機功率 Installation power:1.5kW

(5)外形尺寸 (LxWxH):6700 x 1600 x 850mm

(6)重盆 Weight:約1200Kg


2、皮帶運輸機 BZY1113.5/64/850

名稱Name:皮帶運輸機

型號Model:BZY1113.5/64/850

(1)皮帶運輸長度 Belt conveying length:6400mm

(2)皮帶運輸寬度 Belt conveying breadth:1350mm

(3)工作高度 Working height:850mm

(4)裝機功率 Installation power:1.5kW

(5)外形尺寸 (LxWxH):6700 x 1600 x 850mm

(6)重盆 Weight:約1200Kg


3、電動進出料熱壓機  BY625 x 43/40

名稱Name:電動進出料熱壓機

型號Model:BY625 x 43/40

(1)公稱總壓力  Total pressure::4000kN

(2)熱壓板數最及規格  Platen No. & size:2-13000 x 1500 x 90mm

(3)工作層數  Working layer:1

(4)熱壓板間距  Opening:300mm

(5)加壓油缸數量及直徑  Pressing cylinder No. &diameter:30-Φ85mm

(6)提升油缸數量及直徑  Raising cylinder No. & diameter:5-Φ85mm

(7)有效工作幅面最大壓強  Specific pressure:2Kgf/cm2

(8)額定壓力  Rated pressure:23.5MPa

(9)工作溫度  Working temperature:700℃-80℃

(10)進料方式  Loading way:電動,縱向(Automatically,width direction)

(11)壓板開啟方式  Hot platen opening way:電動(Automatically)

(12)閉合速度  Speed of closing:20mm/s

(13)進抖速度  Lading speed:18 m/min(變頻調速Frequency control)

(14)加熱方式  Heating way:電熱介質循環,上、下壓板單獨加熱

(Electric heated with thermic oil, upper and down hot press is controlled separately)

(15)工作溫度  Working temperature:70℃-80℃

(16)工作高度  Working height:850mm

(17)裝機功率  Installation power:303.2kW

(18)外形尺寸(LxWxH):13570 x 3600 x 3500mm

(19)供電制式  Voltage:3PE 380V 50Hz

(20)重量  Weight:約48000Kg


3、皮帶運輸機 BZY1113.5/64/850

名稱Name:皮帶運輸機

型號Model:BZY1113.5/64/850

(1)皮帶運輸長度 Belt conveying length:6400mm

(2)皮帶運輸寬度 Belt conveying breadth:1350mm

(3)工作高度 Working height:850mm

(4)裝機功率 Installation power:1.5kW

(5)外形尺寸 (LxWxH):6700 x 1600 x 850mm

(6)重盆 Weight:約1200Kg


4、皮帶運輸機 BZY1113.5/64/850

名稱Name:皮帶運輸機

型號Model:BZY1113.5/64/850

(1)皮帶運輸長度 Belt conveying length:6400mm

(2)皮帶運輸寬度 Belt conveying breadth:1350mm

(3)工作高度 Working height:850mm

(4)裝機功率 Installation power:1.5kW

(5)外形尺寸 (LxWxH):6700 x 1600 x 850mm

(6)重盆 Weight:約1200Kg
